Features

Powerful Drives – Double reduction planetary drives provide exceptional pushing power, delivering maneuverability, outstanding performance, and the standard two speed travel allows for increased travel speeds.

Dual Flow Auxiliary Hydraulics – Features multiple attachments presets and the ability to change hydraulic flow within the 5.7′ monitor display.

Active Power Control – Maintains engine power for optimal performance, and it may be engaged or disengaged by the operator.

Quiet Ride Track – Allows rollers to ride on a rubber contact pad for reduced vibration and a quieter ride, and the wide block tread improves flotation.

Radial Lift Loader – Is designed to deliver excellent mid-height reach and unmatched performance in the toughest applications.

Total Package – Outstanding operating capacity coupled with tremendous breakout force allow you to get the job done more efficiently.

Built to Last – The heavy duty rear door is built to protect the radiator and hydraulic oil cooler from rear impacts, and will provide years of service and dependability.

Purpose Built Frame – Features multiple cross members for greater strength and rigidity.

Model Specific Oversized Undercarriage Components – For long lasting durability. TL6R features double and triple flange track rollers for less susceptibility to de-tracking.

Rear Bumper with Tie Downs – Delivers greater protection to the rear of the machine and simplifies anchoring the machine for transport.

High Capacity Cooling Module – Enables machine to run cooler and more efficiently for improved component life and attachment efficiency.

Heavy Duty Cross Member – Provides strength and rigidity throughout the loader arm and a low threshold for easy entry/exit and excellent visibility to the attachment.

Pilot Joystick Controls – Respond immediately to operator input for greater control and performance, and they are low effort for excellent comfort.

Rear View Camera - Allows operator full view of the rear of the machine on the in cab 5.7″ color display. Along with a large panoramic rear-view mirror for enhanced visibility to the rear of the machine

Color Multi-Informational Display – Features a 5.7 full color display that provides the operator with pertinent machine information, allows the operator to adjust hydraulic flow from the seat, and has a wide range of attachment presets that can be set-up.

Cabin – Features a larger cab, greater functionality, convenient rocker switch layout, 12v accessory outlet, and multiple cup holders.

Deluxe Suspension Seat – Allows the operator to remain comfortable throughout the workday by providing a wide array of settings that include adjustments for height which also improves attachment visibility.

Swing-Out Door – For the TL6R to accommodate our low profile ROPS/FOPS cab/canopy that can easily enter areas with low overhead clearance.


Simplified Battery Access – Is available through a bolt-on panel located on the left tower.

Rear Tower Clean-Outs – Easy access to high capacity steel hydraulic tank along with hydraulic filters, fill and breather cap.

Open Up – With a tilt back operator’s station and large removable belly pans routine maintenance and cleaning is easy to perform.

Access to Maintenance Items – Many key maintenance items are accessible from the rear of the machine: engine oil fill and filters, engine oil dipstick, coolant reserve tank, fuel water separator, and air cleaner.

Two Large Belly Pans – For easy clean out of dirt and debris. Two smaller access panels for engine oil drain and fuel water separator.
