Komatsu

HD465-10

The HD465-10 features a tight turning radius for maneuverability, while the Komatsu Traction Control System (KTCS) provides optimal traction in challenging conditions. Packed with operator comfort features, the HD465-10 is designed to help keep your crew productive throughout long shifts.

Emission Rating

Tier 4 Final

Net Horsepower

791 HP @2,000 rpm (590 kW @2,000 rpm)

Gross Vehicle Weight

232367 lb (105400 kg)

Heaped Body Capacity

48.5 yd³ (37.1 m³)

Payload

61.2 U.S. tons (55.5 metric tons)

Download HD465-10 Brochure

Features

Regulate fuel efficiency for lighter work on flat ground with ‘economy’ and ‘economy light’ modes. For higher production jobs and uphill hauling, use ‘power’ mode to increase engine maximum output and raise the upshift and downshift engine speeds during operation.

Maneuver in and out of tight spaces with a tight turning radius (28’ 7"). The MacPherson strut-type independent front suspension features an A-arm wheel-to-main frame design for wider spacing and easy access to the engine bay.

Handle steep grades with fully hydraulic-controlled wet multiple-disc brakes on the rear axle. These large-capacity, continuously-oil-cooled brakes also function as a responsive retarder, giving operators confidence at higher downhill speeds.

Control downhill descent by setting your desired travel speed with the automatic retard speed control (ARSC), which automatically applies the brake retarder to maintain the desired setting and descend the road with confidence.

Operate at peak efficiency with the Komatsu Advanced Transmission with Optimum Modulation Control System (K-ATOMiCS). Designed to help avoid unnecessary fuel consumption and reduce material spillage by automatically selecting a gear depending on grade, speed and acceleration.

Stay focused while operating in loose or slippery haul road conditions with Komatsu's Traction Control System (KTCS), which monitors the rear wheels for slippage and automatically applies the brakes independently to each wheel for enhanced traction.

Cast-steel components are used in critical areas of the main frame where loads and shocks are most concentrated for increased machine durability.

Inclined stairs with handrails provide easy access to the cab and service deck.

Cast-steel components are used in critical areas of the main frame where loads and shocks are most concentrated.

PLM is a tool to manage the hauling cycle payloads and to analyze the production volume and working conditions of the dump truck for specific time periods. Loaded weight is shown on the payload display (on the LCD unit), and by the external display lamps in real time, while loading.

The battery compartment is located at ground level to facilitate daily checks and battery replacement.

Specs & Compare

Printer Friendly Version

Select up to 4 models to compare specifications

Features

CONTROL YOUR FUEL CONSUMPTION

NAVIGATE TIGHT SPACES

TRAVERSE GRADES WITH CONFIDENCE

STAY FOCUSED ON THE ROAD

SMOOTH ADAPTABILITY WITH K-ATOMICS

KOMATSU TRACTION CONTROL SYSTEM (KTCS)

HIGH RIGIDITY FRAME

CONVENIENT ACCESS

HIGH RIGIDITY FRAME

INTEGRATED PAYLOAD METER

GROUND ACCESSIBLE BATTERY COMPARTMENT
