Tier 4 Final
2385 HP @1,800 rpm1778 kW @1,800 rpm
901400 lb408875 kg
207 yd3158 m3
250 U.S. tons227 metric tons
Tier 4 Final
2385 HP @1,800 rpm1778 kW @1,800 rpm
901400 lb408875 kg
207 yd3158 m3
250 U.S. tons227 metric tons
As part of a complete service and support program, Komatsu equips every mining and quarry sized machine with KOMTRAX Plus 2®. By using a satellite-based communication system, KOMTRAX Plus 2® offers a new vision of monitoring your valuable assets. By providing insight to critical operating metrics the user can manage increased availability, lower owning and operating costs and maximize fuel efficiency.
The information available through KOMTRAX Plus 2® allows service personnel to review faults and trends, improve the quality of the troubleshooting process and reduce unscheduled machine downtime.
Structurally Enhanced Frame Design
By using advanced computer-aided design, finite element analysis, and full-scale dynamic testing, the frame has been designed to carry 227 metric tons 250 short tons and provides the high structural reliability Komatsu is known for.
Castings in High Stress Areas
To increase frame reliability, steel castings have been incorporated at key frame pivot points and critical load bearing portions of the structure. This includes the rear body pivot and horsecollar sections.
Simple and Reliable Hydraulic System
The hydraulic system is a proven and reliable design with fewer parts than other OEMs. The system utilizes a single tank, providing one common source of fluid for steering, braking, and hoisting. In-line, replaceable filtration elements provide protection from hydraulic system contamination, making the system easier to service.
